Side by Sides for Farming for Sale in Hamilton, Innisfil & Peterborough

A side-by-side farm vehicle is just what you need to make taking care of chores and farming tasks easier. When you are looking for the best UTV for farm use, you’ll want to find an option that offers the versatility and performance features you need most. Thankfully, finding a farm UTV is simple when you come to the experts at DeWildt Marine & Powersports.

With more than 20 years experience, our family-owned business is committed to providing you with a no pressure and enjoyable purchasing experience that is centered around your unique needs. Contact us today and find a farm side-by-side that helps you get any task done with ease.

Back

2025 Honda Pioneer 520 Standard Hero Red

Name: 2025 Honda Pioneer 520 Standard Hero Red
Brand: Honda
Availability: OutOfStock

Call Email

Call for Price

Contact Us Get Approved Value a Trade Get Directions Get Directions Print

Overview

Honda Pioneer 520 Side-by-Side

Sized right and loaded with features. The Honda Pioneer 520 is all about striking the right balance – between compact size and functionality, between power and versatility. It’s tough but nimble, and always ready to deliver.

Specifications

Model

Pioneer

Category Name

UTV - Side x Side

Year

2025

Sale Type

New

Manufacturer

Honda

Color

Hero Red

Tires

Front: 24 x 8 - 12, 4 ply rating Rear: 24 x 10 - 12, 4 ply rating

Width

1,270 mm (50.0 in)

Brakes

Front: Dual 200 mm discs Rear: 170 mm disc

Colour

Avenger Red, Atera Camo

Height

1,809mm (71.2 in)

Length

2,668 mm (105 in)

Warranty

12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus

Wheelbase

1,855 mm (73.0 in)

Curb Weight

484 kg (1,067 lb) including required fluids and full tank of gas – ready to ride

Engine Type

Liquid-cooled longitudinally mounted single-cylinder

Final Drive

2WD/4WD; direct front and rear driveshafts with switchable 2WD/4WD

Valve Train

OHV, 2 valves

Bed Capacity

204 kg (450 lb)

Displacement

518 cc

Transmission

Five-speed automatic transmission with AT/MT modes with paddle shifting and reverse.

Bore & Stroke

96 mm x 71.5 mm

Fuel Capacity

15.4 liters, including 4.2-liter reserve

Fuel Delivery

PGM-FI electronic fuel injection

Rear Suspension

Independent double wishbone with adjustable hydraulic shocks; 150 mm (5.9 in) travel

Towing Capacity

453 kg (1,000 lb)

Front Suspension

Independent double wishbone with hydraulic shocks; 147 mm (5.8 in) travel

Ground Clearance

217 mm (8.5 in)

Compression Ratio

9.5:1

engine and drivetrain

Efficient engine

The Pioneer 520’s liquid-cooled engine is mounted longitudinally. By orienting the crankshaft front to back in the chassis, the flow of power is straight to the wheels without any right angle detours, reducing powertrain friction and putting more grunt to the ground.

Ample ground clearance

By using an overhead-valve layout and a semi-dry-sump lubrication system, engine height is significantly reduced, lowering centre of gravity while also improving ground clearance.

Tackle any terrain

Shiftable 2WD/4WD system provides the efficiency of two-wheel drive while retaining the ability to select 4WD quickly via a dash-mounted lever when conditions demand.

Advanced transmission

The availability of both automatic and manual shifting functions gives you the best of both worlds. Choose AT mode for fully automatic shifting, or override the AT settings on the fly with paddle shifters mounted on the steering wheel. Want to shift manually? Simply choose MT mode and operate the five speed transmission manually with the paddle shifters. It’s the best of all worlds.

Smooth shifting

By re-tuning the transmission’s automatic-mode shift map, engineers were able to reduce shift shock for even smoother operation.

Crisp performance

Electronic fuel-injection system provides crisp performance and helps ensure trouble-free starting and operation in cold conditions and changing altitudes.

Accessory power

Powerful 481 watt AC generator has generous output to run electronic accessories.

Low noise

The stainless steel exhaust system keeps noise levels low while also including a certified spark arrester for when you’re riding in regulated or sensitive environments.

More Power

Need extra power? The Pioneer 520 delivers with its improved 518 cc liquid-cooled engine. That extra 43 cc provides a torque boost and increased low-to-midrange performance that make tough jobs or tough trails even easier to handle.

chassis and suspension

Durable construction

A strong steel chassis is designed to help the Pioneer 520 remain stable in rough going, and its heavy-duty construction will help it stand up to rough punishment on the job site or recreational trail.

Improved handling & comfort

The independent front and rear suspension systems — with improved spring rates, damping performance and updated front A-arms — provide comfort and control over even tough terrain. Plus, the rear swaybar has been removed to make for an even smoother ride.

Dynamic control

With 147 mm (5.8 in.) of front suspension travel and 150 mm (5.9 in.) at the rear, plus 217 mm (8.5 in.) of ground clearance, the Pioneer 520 can negotiate difficult terrain with ease.

Roomy seating

Roomy cab and bench seat are designed for a comfortable fit for two. Twin cup holders make it easier to stay hydrated when stopping for a rest out on the trails or work site.

Towing ability

Heavy-duty receiver-style hitch lets you tow up to 453 kg (1,000 lb).

additional features

Durable tilt box

Working with a heavy load just got a whole lot easier. The Pioneer 520’s gas-assisted tilt box can carry a full 450 lb of wood, gravel, tools, and feed with a slot for 3/4 inch plywood and patterned slots shaped into the bed for milk crates and buckets. And with a secure tailgate and a suite of available Pro-ConnectTM modular accessories, you might never run out of ways to put your Pioneer to work. But when it is time to take a break, enjoy the added comfort of the cup holder rings in the tailgate.

Easier maintenance

Attractive, rugged bodywork gives the Pioneer 520 an aggressive, functional look. The easily removable hood and seat cushions, plus the repositioned battery and air filter, also help to simplify maintenance.

Smart design

Waterproof accessory socket provides convenient 12-volt power whenever you need it.

Safety first

High sill doors, integrated headrests, protective door nets, automotive-type 3-point Emergency Locking Retractor (ELR) seat belts and stout Occupant Protection Structure help to keep driver and passenger secure. For added safety, a speed limiter prevents travel faster than 24 km/h if it detects that a seat belt isn’t being worn.

Easy entry

Clever rear-hinged door design allows the nets to remain attached when opening the doors, easing entry and exit. Doors feature a single-handed twist-action release mechanism, equally accessible from both inside and outside the Pioneer 520. Automotive-style double latches allow the doors to latch securely when pulled shut.

Bright illumination

Twin-headlight system features 37.5-watt headlights with a focused light distribution pattern for improved visibility after dark. LED brake lights and taillights provide optimal illumination and conspicuity.

Information at a glance

The easy-read digital dash includes a large speedometer, gear position indicator, fuel gauge, maintenance minder, and warning lights for critical engine and drivetrain functions.

Helpful accessories

A wide array of easy to install Pro-ConnectTM modular accessories, including numerous ways to add storage and carrying ability, contribute to the Pioneer 520’s versatility. Plus, trusted Honda durability, quality and reliability help improve retained value over the life of the machine.
